Ȩ > Jantzen, Denmark > Silver Gold Z-Cap
Silver Gold Z-Cap


Á¦Á¶»ç Jantzen, Denmark
»óÇ°ÄÚµå ep0715
ÆǸŴÜÀ§
ÆǸŰ¡ 68,000¿ø
¿É¼ÇÀû¿ë°¡ : 68,000¿ø
Çʼö¼±Åà :
ÁÖ¹®¼ö·®
EA
Àû¸³±Ý 800¿ø
Àç°í ¹«Á¦ÇÑ
¹Ù·Î ±¸ÀÔ Àå¹Ù±¸´Ï¿¡ ´ã±â À§½Ã¸®½ºÆ®¿¡ ³Ö±â


»ó¼¼ Á¤º¸



** °øÁö»çÇ× **

- ȯºÒ ¹× ±³È¯ ºÒ°¡ -

ÀϺΠ°í°´µéÀÌ Å×½ºÆ® ÈÄ ¹ÝÇ° ¹× ±³È¯À» ÇÏ´Â »ç·Ê°¡ ÀÚÁÖ ÀÖ¾î ºÎµæÈ÷ÇÑ Á¶Ä¡ÀÓÀ» ¾çÇØÇØ Áֽñ⠹ٶø´Ï´Ù.





Silver gold Z-cap
More resolution, more sound stage. Lots of dynamics, fast reaction, live feeling and natural sound.



Product Description:

The SilverGold Z-cap makes an extraordinary appearance: delivering a rich sound, full of tonal colors, but without any coloration ¡¦ and crystal clear without the slightest hint of sharpness.

You can almost feel the fine details and rich texture in midtones and treble, sans any compromise! From its remarkable, fine-tuned micro dynamics, the SilverGold Z-cap creates a fascinating, bigger-than-life orchestra – every instrument and note in perfect harmony.

The Jantzen Audio SilverGold Z-cap is also very versatile. Use it in a speaker crossover or as a coupling cap in an amplifier – even in a power supply it shows its mastery.






Download product information here:

Download PDF

(Right click + ¡®save link as¡¯ to save file)

Download list of values here:

Download PDF

(Right click + ¡®save link as¡¯ to save file)

Technical Specifications:

1 Silver/Gold Metallized Polypropylene

2 Metallisation 99% Silver and 1% Gold

3 Non inductive construction

4 Range 0.01uF to 10uF

5 Tolerance +/-2%

6 Loss factor  1K 0.00002  10K 0.00001

7 Dialectric strength 1200VDC 800VDC 250VDC


Silver Gold Z-cap dimensions:

0.22uf   =45,5mm x 22,5mm (1200VDC)
0.33uf   =45,5mm x 25.5mm (1200VDC)
0.47uf   =43,5mm x 16,5mm (800VDC)
0.68uf   =43,5mm x 16,5mm (800VDC)
0.82uf   =43,5mm x 18,5mm (800VDC)
1.0uf     =43,5mm x 18,5mm (800VDC)
2.2uf     =45,5mm x 25.5mm (800VDC)
2.7uf     =45,5mm x 31,5mm (800VDC)
3.3uf     =45,5mm x 22,5mm (250VDC)
3.9uf     =45,5mm x 26,5mm (250VDC)
